Product Description:
904tractor , 90HP4WD, YTO engine, air-conditioned cab
12 F + 12R synchronizer gearbox, radial tires 8.3-24/14.9-30,' two
sets of hydraulicqutput, 11-inch double
acting clutch, imported Gramer seat, rear counterweight,Hydraulic
auxiliary 7 5 L| oil tank,
PTO540/1000 or 540/760
Features:
- Product Name: Agricultural Tractor
- Pto Speed: 540/1000
- Starting Method: Electricity
- Gear Shifts: 12+12
- Drive Type: Gear Drive
- Horsepower: 90 Hp
Technical Parameters:
Tractor
Parameters | Model | 904 |
|
| Drive Type | 4WD |
|
| Overall Dimensions L×W×H(mm): | 4100x1950x2780 |
|
|
| Wheel Track (mm) | Front axle | 1400/1450/1500/1550 |
|
| Rear axle | 1300-1800 |
|
|
| Wheel Bass(mm) | 2350 |
|
| Ground Clearance (mm) | 460 |
|
| Rated Traction Force(N) | 17500 |
|
|
| Construction Mass(kg) | 3700 |
|
|
Theoretical Speed
(km/h) | Forward | 2.46—32.73 |
|
|
| Reverse | 2.15—28.69 |
|
|
Engine
Specifications | Model | 3E22RT51P904 |
|
|
| Type | 4-Cylinder Vertical,water cooled,4
stroke cycle |
|
|
|
|
| Rated Power(kw/hp) | 76.2 |
|
|
| Rated Speed (rpm) | 2400 |
|
|
| Bore×Stroke (mm) | 90×100 |
|
|
| Total Displacement(L) | 2.55 |
|
|
Drive
System | Clutch | 11" dual-stage |
|
|
| Gear Box | 12+12 |
|
Traveling
Mechanism | Tyre | Front | 11.2-24 |
|
| Rear | 16.9-30 |
|
| Steering Gear | Full Hydraulic Steering |
|
|
| Brake | Disc type |
|
| Description | |
|
904 tractor,90HP 4WD, Y T O engine , air-conditioned cab,
12 F + 12R synchronizer gearbox, radial tires 8.3-24/14.9-30, two
sets of hydraulic oacting clutch, imported Gramer seat, rear
counterweight,Hydraulic auxiliary 7 5 LPTO540/1000 or 540/760 | utput, 11-inch double- oil tank, |
|
|
|
|
|
|
Packing and Shipping:
Packaging and Shipping of Agricultural Tractor
The Agricultural Tractor will be carefully packaged to ensure its
safe arrival to our customers. Here is the packaging and shipping
process:
Packaging Process:
- The Agricultural Tractor will be wrapped in a protective layer to
prevent any scratches or damage during transportation.
- It will then be placed in a sturdy cardboard box with additional
padding to provide extra protection.
- The box will be sealed and labeled with the product name, model
number, and customer's address.
Shipping Process:
Once the Agricultural Tractor is packaged, it will be shipped using
a reliable and efficient shipping service. Here are the steps we
will take to ensure a smooth delivery:
- We will check all necessary documents and clearances for
international shipments, if applicable.
- The tractor will be loaded onto a secure and well-maintained truck
for land transportation.
- If the tractor is being shipped overseas, it will be loaded onto a
cargo ship.
- During the shipping process, we will continuously monitor the
tractor's progress and provide updates to the customer.
- Upon arrival at the destination, the tractor will be carefully
unloaded and delivered to the customer's address.
At Agricultural Tractor, we take great care in packaging and
shipping our products to ensure their safe arrival. If you have any
questions or concerns about the packaging and shipping process,
please don't hesitate to contact us. We are dedicated to providing
the best service possible for our customers.
